Name: Professional Rotomoulding Mould For Water Tank Manufacturing
Brand: Wuxi Yisong Rotomolding Technology Co., Ltd.
SKU: Customize
Price: 2,550.00 USD
Availability: InStock

Home Products Rotomoulding Mould

Professional Rotomoulding Mould For Water Tank Manufacturing

Product Details:

Place of Origin:	China
Brand Name:	YISONG
Certification:	CE ISO
Model Number:	Customize

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	Negotiation
Packaging Details:	customary packing
Delivery Time:	30-45 work days
Payment Terms:	L/C, T/T
Supply Ability:	1000 Set/Sets per Year

Contact Now

Detailed Product Description

Features:	High Precision, Durable, Corrosion Resistant	Warranty:	Yes
Material:	Steel Or Aluminum	Hs Code:	8480790090
Surface Treatment:	Polishing,Slot Blasting	Storage Objects:	Liquid
Uselife:	10000 Cycles	Wall Thickness:	8-10mm
Capacity:	100-5000 L Customised	Color:	Green
Tolerance:	±0.1mm	Type:	Outdoor Slide
Surface Finish:	Mirror Polish	Design:	Customized
Mold Process:	Plasma Cutting + Handwork
Highlight:	Water Tank Rotomoulding Mould , Professional Rotomoulding Mould , Water Tank Manufacturing Rotomoulding Mould

Rtational Moulding Mould for Septic tank mold

Specification

Name	Water Tank Mould
Shaping Mode	Rotomolding Mould / Rotational Moulding Mould
Surface Treatment	Polishing,Slot Blasting
Wall Thickness	8-10mm
Capacity	100-5000 L Customised(250ml,500ml,750ml,1000ml,2500ml Available)
Material	Sheet Metal, Mild Steel
Uselife	10000 Cycles
Mold Process	Plasma Cutting + Handwork
Shape	Vertical / Horizantal
Feature	With Lid,Water Inlet,Outlet,Valve
Plastic Product Material	Lldpe, Mdpe, Hdpe, Cross Linked Pe
Certifications	Iso 9001 ,Arma 2019 2020,2021,2022
Application	Drinking Industry
Color	Customized
Our Service	Help You Design With Our Professional Experience For Rotational Mold
Oem / Odm	Yes
Mould Life	1 Year
Mould Production Cycles	15-60 Days

Rotational moulding, known also as rotomolding or rotocasting, is a process for manufacturing hollow plastic products. For certain types of liquid vinyls, the term slush molding is also used. Rotational molding has particular advantages in terms of relatively low levels of residual stresses and inexpensive molds. Rotational molding also has few competitors for the production of large (> 2 m3) hollow objects in one piece. Rotational molding is best known for the manufacture of tanks but it can also be used to make complex medical products, toys, leisure craft, and highly aesthetic point-of-sale products.

The process begins with specially developed and uniquely applied resins. They can include plastisols, polyethylene, polycarbonate, acetate butyrate, polyamide, elastomers, polyurethane, polypropylene, ethylene vinyl acetate and fluorocarbons. Some of the most advanced work is being done with cross-linked polyethylene and even nylon.

The principle of rotational molding of plastics is simple. Basically the process consists of introducing a known amount of plastic in powder, granular, or viscous liquid form into a hollow, shell-like mold.The mold is rotated and/ or rocked about two principal axes at relatively low speeds as it is heated so that the plastic enclosed in the mold adheres to, and forms a monolithic layer against, the mold surface. The mold rotation continues during the cooling phase so that the plastic retains its desired shape as it solidifies. When the plastic is sufficiently rigid, the cooling and mold rotation is stopped to allow the removal of the plastic product from the mold. At this stage, the cyclic process may be repeated. The basic steps of (a) mold charging, (b) mold heating, (c) mold cooling, and (d) part ejection are shown in Figure below.

Professional Rotomoulding Mould For Water Tank Manufacturing 0

Our Certifications
CE Certification of Rotational Mold
CE Certification of Rotational Molding Machine
Member of the Association of Rotational Moulders Australasia 2019 2020,2021,2022
ISO 9001 Quality Management System Certificate
Rotomoulding Professional Committee of ChinaPlastics Processing Industry Association
12 Patent/Utility Model Patents
Professional Rotomoulding Mould For Water Tank Manufacturing 2
